PG3A – Centrifugal Dewatering Pump 3″ – Petrol
SKU
5000007659
Category Portable Centrifugal & Trash Pumps
Remove clean water from your job site fast and economically with the PG 3 dewatering pump. This simple, easy to use pump is designed to move water up to 264 gpm (1000 L/min) with very little solids, up to 0.25-inch (6.5 mm). With its self-priming centrifugal pumping action and overall compact size, the pump is ideal for the contractor with the need for temporary water removal.
– Cast iron impeller and volute are wear resistant for long life and minimal service.
– Pump out vanes on back of impeller reduce debris accumulation and downtime while allowing greater productivity.
– Carbon ceramic mechanical seal teamed with reliable four-cycle engine with low oil shutdown provides for increased operating life.
– High strength lightweight die cast aluminum housing increases the years of trouble-free pump life. A heavy duty protective frame provides convenient carrying handles while adding extra protection for the pump.
Technical Specifications
Dimensions (L x W x H) | 514 x 404 x 462 mm |
Diameter suction and discharge | 76.2 mm |
Operating weight | 29 kg |
Discharge head | 27 m |
Discharge capacity | 1,097 L/min |
Suction height lift | 7.6 m |
Solids diameter max. size | 6.5 mm |
Engine / Motor | |
Engine / Motor type | Air Cooled Single Cylinder |
Engine / Motor manufacturer | Honda |
Engine / Motor model | GX160W1C2 |
Displacement | 163 cm³ |
Max engine speed | 3,600 rpm |
Operating speed | 3,600 rpm |
Power (max. rated) | 3.6 kW |
Power rating specification | SAE J1349 |
Engine oil capacity | 0.6 L |
Fuel type | Petrol |
Fuel consumption | 1.8 L/h |
Fuel tank capacity | 3.6 L |
Run time | 2.1 hrs |
